High Quality 32 Segments Armature Commutator For Power Tools

High Quality 32 Segments Armature Commutator For Power Tools The commutator can be defined as is an electrical rotating switch in a particular type of generators as well as motors. This is mainly used to overturn the direction of current among the external circuit & rotor. It comprises a cylinder with numerous metal contact segments lying on the revolving armature of the machine. The brushes or electrical contacts are made with a carbon press material next to the commutator, designing sliding contact by consecutive segments of the commutator while it revolves. The armature windings are allied to the segments of the commutator.

Model:NDPJ-HXQ-03006

Send Inquiry

Product Description

High Quality 32 Segments Armature Commutator For Power Tools

1.Product Introduction

The commutator can be defined as is an electrical rotating switch in a particular type of generators as well as motors. This is mainly used to overturn the direction of current among the external circuit & rotor. It comprises a cylinder with numerous metal contact segments lying on the revolving armature of the machine. The brushes or electrical contacts are made with a carbon press material next to the commutator, designing sliding contact by consecutive segments of the commutator while it revolves. The armature windings are allied to the segments of the commutator.

Product name:	DC motor part commutator
OD	37.5
ID	φ13
Total Height	26
Segment Length	23
Hook/Riser dia.	38.5
Bar No.	32

2.Product Parameter (Specification)

Part No.	O.D (D)	I.D (d)	Total O D (D1)	Bar No(N)	Bar length (L1)	Total length (L)
JZQE-RS12-148	63	13.2	73	24	16	26.5
JZQE-RS12-148B	63	20	73	24	16	26.5
JZQE-RS12-148C	63	13.2	73	24	16	26.5
JZQE-RS12-149	40	15	43	43	10	18.2
JZQE-RS31-150	44	12.08		23	10	12.5
JZQE-RS31-150B	44	12.35		23	10	12.5
JZQE-RS31-150C	44	12.06		23	10	12.5
JZQE-RS31-150D	44.2	12.08		23	10	12.5
JZQE-RS31-150E	44	12		23	10	12.5
JZQE-RS12-151	47.6	13.2	57	16	14	24.5
JZQE-RS12-151B	47.6	13.2	57	16	14	22
JZQE-RS12-151C	47.6	13	57	16	14	24.5
JZQE-RS12-151D	47.6	13	57	16	14	22
JZQE-RS12-151E	47.6	13.4	57	16	14	24.5
JZQE-RS31-169	38	12.08		26	10	14.3
JZQE-RS12-193	74	33	85	81	12	12
JZQE-RS12-247	19.5	4		7	3	5.5
JZQE-RS12-326	49	13.2		16	14	15
JZQE-RS32-348	58	24.1		25
JZQE-RS32-464	20.5	5	25	8	5.7	8.5
JZQE-RS32-464B	20.5	5	24.7	8	5.7	8.5
JZQE-RS32-464C	20.5	5	24.7	8	5.7	8.5
JZQE-RS32-464D	20.5	5	25	8	5.7	8.5
JZQE-RS32-464E	20.5	5	25	8	5.7	8.5
JZQE-RS12-480	78	23		25	13	23
JZQE-RS32-508	20.5	3.175	25	8	4.2	8.5
JZQE-RS31-525	44.2	12.08		23	10	13
JZQE-RS31-525B	44.2	12.35		23	10	13
JZQE-RS31-525C	44.2	12		23	10	13
JZQE-RS32-555	20.5	3	24.7	8	5.7	8.6
JZQE-RS12-593	71.5	13.2	64	24	28	32.5
JZQE-RS11-608	52.5	16		19	6.5	16
JZQE-RS11-608B	52.5	16		19	6.5	16
JZQE-RS32-618	23	4	28.5	10	6.5	10
JZQE-RS32-618B	22.5	4	28	10	6.5	10
JZQE-RS32-651	47.6	13	56.5	16	12.5	18.5
JZQE-RS32-664	48	13.4	57.5	16	12.5	24.5
JZQE-RS12-688	59	24.1	58	25	34.9	22
JZQE-RS12-689	59	24.1	58	25	34.9	19.5
JZQE-RS32-717	47.6	13.3	56.5	16	12	24.77
JZQE-RS32-739	44.2	13.8		23	10	13
JZQA-RS12-752	31	11.5	40	21	25.5	28
JZQB-RS31-792	61	13.5		29	9	16
JZQE-RS31-796	44.2	9		23	10	12.5
JZQE-RS12-846	48.5	10.2	48.5	25	6	11
JZQE-RS32-854	47.6	13.2	56.6	16	7	22
JZQE-RS12-907	48.5	10.2	48.5	25	6	10
JZQE-RS12-926	64	20	60	31	5	17

3.Product Feature And Application

This commutator is used in AC motor, single phase motor, automobile motors, motorcycle starter motors, power tool motors and micro special motors.

4.Product Details

Single motor commutator for AC motor
